2260SB1300
- Foldable front and back panel
- Higher sides for bigger loading volume
- Strong internal lashing eyes
The trailer has reinforced side panels with higher sides (40 cm) for higher loading volume. The trailer is easy to load and have foldable front and back panel for loading of longer goods. All versions are fitted with internal lashing eyes for secure loading of goods.
As always Brenderup offers a wide accessory program for our trailers. Images are for illustrative purposes only and may show optional equipment.
Features and benefits
Foldable back panel
Foldable back panel to easier load the trailer and also enable you to transport longer goods.
High back panel
For larger loading volume
Foldable front panel
Foldable front panel to easier load the trailer and also enable you to transport longer goods.
High sides 40 cm
40 cm high sides provides larger loading volume
13-pol cable
The trailer is delivered with a modern 13-pol connector.
Strong drawbar
Strong side locks
High quality side locks which firmly locks the panels
Specifications
2260SB1300 | |
Article number | 311799 |
Gross weight (kg) ? | 1300 |
Load (kg) ? | 1020 |
Unladen weight (kg) | 280 |
Int dimensions (cm) ? | 258x128x40 |
Ext dimensions (cm) ? | 405x178x94 |
Loading height (mm) | 535 |
Type of sidepanel | Steel |
Foldable back panel | Yes |
Foldable front panel | Yes |
Foldable side panels | No |
Tip | No |
Prepared for tip | No |
Tip-protection | No |
Brakes | Yes |
Number of axels | 1 |
Tyre dimension | 195/70R14 |
No of wheelbolts | 5 |
Rim type | Steel |
Mudguards | Non standable |
Plug connection type ? | Straight |
Adaptercable | 13 |
Jockey wheel | Yes |
Coupling | Steel sheet |
Internal lashing eyes | 6 |
External hooks | 4 |
Premounted cover buttons | Yes |
